US PRO Industrial 8614 1 Inch Drive Air Impact Wrench 9 Inch Anvil 3200Nm

When the job moves from cars to commercial vehicles, plant equipment, and heavy-duty maintenance, a standard impact wrench simply runs out of muscle. The US PRO Industrial 8614 1 Inch Drive Air Impact Wrench is built for those moments—where seized wheel nuts, large chassis bolts, and industrial fasteners demand serious torque and steady control.

At its core is a powerful pneumatic system capable of delivering up to 3200Nm of maximum torque, paired with a 9 inch anvil that gives you the reach needed around deep wheel hubs and awkward access points. The tool runs at a free speed of 3200rpm, helping speed up repetitive removal and rundown work without sacrificing impact strength when it matters most.

For controlled performance, it features three forward speed settings and one reverse, allowing you to match power to the task—whether you’re breaking loose stubborn fasteners or running them down efficiently. A side exhaust helps direct airflow away from the operator and working area, while the industrial build is designed to handle demanding use day after day.

This model operates across an air pressure range of 113 to 142 psi, uses a 1/2 inch air inlet, and is designed for a 13mm air hose to support the higher air demand expected of 1 inch drive tools. UKCA conformity makes it a reliable choice for professional workshop environments where performance and compliance both matter.

Key Features

• 1 inch square drive for heavy-duty impact sockets

• 9 inch anvil for improved reach on deep-set fasteners

• Up to 3200Nm maximum torque for tough removal work

• 3200rpm free speed for fast operation

• Three forward speeds and one reverse for controlled power delivery

• Side exhaust to direct airflow away from the user

• Built for large fasteners up to 39mm bolt capacity

• UKCA compliant for professional use

Specifications

• Brand: US PRO Industrial

• Model: 8614

• Drive Size: 1 Inch Square

• Anvil Length: 9 Inch

• Maximum Torque: 3200Nm (2360 ft-lb)

• Free Speed: 3200rpm

• Air Consumption: 53 CFM (25 l/s)

• Operating Air Pressure: 113 to 142 psi (8 to 10 kg/cm²)

• Air Inlet: 1/2 Inch

• Recommended Air Hose Size: 13mm

• Bolt Capacity: 39mm

• Noise Level: 99 dB(A)

• Vibration: 16.8 m/s²

• Speeds: 3 Forward, 1 Reverse

• Exhaust: Side

• Net Weight: 14.2kg

• Conformity: UKCA

What’s Included

• US PRO Industrial 8614 1 Inch Drive Air Impact Wrench 9 Inch Anvil

• Retail packaging
