Milwaukee M12 Fuel 16 mm SDS Plus Compact Hammer Kit

Built for professionals who need power without bulk, the Milwaukee M12 Fuel 16 mm SDS Plus Compact Hammer Kit delivers impressive performance in a lightweight and perfectly balanced 12 V platform. Designed for drilling and light chiselling in concrete, masonry, and hard materials, this compact rotary hammer is ideal for electricians, installers, HVAC engineers, and maintenance professionals working in confined or overhead spaces.

At the heart of this tool is Milwaukee’s advanced FUEL technology, combining a POWERSTATE brushless motor, REDLITHIUM battery technology, and REDLINK PLUS electronic intelligence. Together, these systems deliver consistent power, extended runtime, and long term durability, even under demanding site conditions. With 1.15 J of impact energy and optimised drilling performance between 5 mm and 12 mm, the tool punches well above its size while maintaining excellent control and precision.

The four mode selector allows seamless switching between rotary hammer drilling, hammer only chiselling, rotation only drilling, and variolock chisel positioning. This versatility makes the tool suitable for everything from anchor fixing and cable routing to light surface preparation work. An integrated anti vibration system, combined with the supplied anti vibration side handle, significantly reduces user fatigue, allowing longer working sessions with improved comfort and control.

Supplied as a complete kit with two high capacity 5.0 Ah batteries, a charger, and a durable HD box, this set is ready for professional use straight out of the case. Compatibility with the full Milwaukee M12 battery platform ensures maximum flexibility across your existing tools.

Key Features

• Compact and lightweight 12 V SDS Plus hammer designed for professional drilling and light chiselling

• 1.15 J of impact energy for efficient performance in concrete and masonry

• Four mode operation including rotary hammer, hammer only, rotation only, and variolock chisel positioning

• POWERSTATE brushless motor for increased durability and consistent power output

• REDLINK PLUS electronic intelligence for overload protection and optimised tool performance

• Anti vibration system with additional anti vibration side handle for reduced user fatigue

• Optimised drilling capacity from 5 mm to 12 mm for anchor and fixing work

• Flexible battery system compatible with all Milwaukee M12 batteries

• Supplied as a full kit with batteries, charger, and HD box for protection and transport

Specifications

• Voltage: 12 V

• Impact Energy: 1.15 J

• Max Drilling Capacity in Concrete: 16 mm

• Optimised Drilling Range in Concrete: 5 to 12 mm

• Max Percussion Rate: 4,410 bpm

• No Load Speed: 0 to 1200 rpm

• Tool Reception: SDS Plus

• Weight with Battery: 2.3 kg with M12 5.0 Ah battery

• Sound Power Level: 99 dB(A)

• Sound Pressure Level: 91 dB(A)

• Vibration Drilling into Concrete: 12.3 m/s²

• Vibration Chiselling: 10.3 m/s²

• Supplied With: Side handle, depth gauge, grease

• Case Type: HD Box
